SH-PH-091
Surface consumer unit, 10 way, with main switch and miniature circuit breakers
Electrical, Motors and Automation
A ten way surface consumer unit supplied populated: a 100 A main switch and a set of C curve miniature circuit breakers already fitted and wired to the busbar, with the way plate labelled. Ready to terminate rather than assemble on site.
Confirmed on the quotation: Breaker ratings per way are confirmed on the quotation.
Electrical ContractingConstruction
Specification
| Reference | SH-PH-091 |
|---|---|
| Ways | 10 |
| Main switch | 100 A |
| Breakers | C curve, fitted and busbarred |
| Enclosure | Surface, white |
